X3D Model Documentation: NavigationInfoExample.x3d

  1  <?xml version="1.0" encoding="UTF-8"?>
  2  <!DOCTYPE X3D PUBLIC "ISO//Web3D//DTD X3D 3.3//EN" "https://www.web3d.org/specifications/x3d-3.3.dtd">
  3  <X3D profile='Immersive' version='3.3'  xmlns:xsd='http://www.w3.org/2001/XMLSchema-instance' xsd:noNamespaceSchemaLocation='https://www.web3d.org/specifications/x3d-3.3.xsd'>
  4       <head>
  5            <meta name='title' content='NavigationInfoExample.x3d'/>
  6            <meta name='description' content='NavigationInfo override example for Kelp Forest world.'/>
  7            <meta name='creator' content='Leonard Daly and Don Brutzman'/>
  8            <meta name='created' content='14 November 2005'/>
  9            <meta name='modified' content='27 July 2024'/>
 10            <meta name='info' content='Contained Inline scene has profile Immersive'/>
 11            <meta name='reference' content='https://X3dGraphics.com'/>
 12            <meta name='reference' content='https://www.web3d.org/x3d/content/examples/X3dResources.html'/>
 13            <meta name='rights' content='Copyright (c) 2005, Daly Realism and Don Brutzman'/>
 14            <meta name='subject' content='X3D book, X3D graphics, X3D-Edit, http://www.x3dGraphics.com'/>
 15            <meta name='identifier' content='https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/Chapter04ViewingNavigation/NavigationInfoExample.x3d'/>
 16            <meta name='generator' content='X3D-Edit 4.0, https://savage.nps.edu/X3D-Edit'/>
 17            <meta name='license' content='../license.html'/>
 18       </head>
<!--
<!-- -->

<!-- to top Index for DEF nodes: DEFAULT_EXAMINE_FIRST, FLY_FIRST, SIT_TIGHT
-->
 19       <Scene>
 20            <!-- Because these NavigationInfo nodes are here in the parent scene, the first one is bound at load time, and thus governs the active navigation modes -->
 21            <!-- Note that an author can control what choices a user has available, and initial type selected, while the user can select among navigation choices from available options -->
 22            <!-- Author TODO: Experiment by swapping order of these NavigationInfo nodes, first one is bound at load time -->
 23            <WorldInfo title='NavigationInfoExample.x3d'/>
 24            <NavigationInfo DEF='DEFAULT_EXAMINE_FIRST'/>
 25            <NavigationInfo DEF='FLY_FIRST' type='"FLY" "ANY"'/>
 26            <NavigationInfo DEF='SIT_TIGHT' type='"NONE"'/>
 27            <!-- Also note that this scene does not provide a way to select a different NavigationInfo node during run time -->
 28            <Inline   url=' "../HelloWorld.x3d" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/HelloWorld.x3d" "../HelloWorld.wrl" "https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/HelloWorld.wrl" '/>
 29       </Scene>
 30  </X3D>
<!--
<!-- -->

<!-- to top Index for DEF nodes: DEFAULT_EXAMINE_FIRST, FLY_FIRST, SIT_TIGHT
-->
X3D Tooltips element index: head, Inline, meta, NavigationInfo, Scene, WorldInfo, X3D, accessType and type, XML data types, field types
-->
<!-- Online at
https://www.web3d.org/x3d/content/examples/X3dForWebAuthors/Chapter04ViewingNavigation/NavigationInfoExampleIndex.html -->
<!-- Version control at
https://sourceforge.net/p/x3d/code/HEAD/tree/www.web3d.org/x3d/content/examples/X3dForWebAuthors/Chapter04ViewingNavigation/NavigationInfoExample.x3d -->

<!-- Color legend: X3D terminology <X3dNode DEF='idName' field='value'/> matches XML terminology <XmlElement DEF='idName' attribute='value'/>
(Light-blue background: event-based behavior node or statement) (Grey background inside box: inserted documentation) (Magenta background: X3D Extensibility)
-->

to top <!-- For additional help information about X3D scenes, please see X3D Tooltips, X3D Resources, and X3D Scene Authoring Hints. -->
